With modern power electronics and advanced microprocessor technology, Delta's AC Motor Drives are able to efficiently control motor speed, improve machine automation and save energy. Taking advantage of our strong position in power electronics technology, Delta's VFD Series of AC motor Drives has evolved rapidly.
Delta VFD-E Series Pdf User Manuals. View online or download Delta VFD-E Series User Manual. Thank you for choosing DELTA’s VFD-L series AC Drive. The VFD-L series is manufactured using high-quality components, material and incorporating the latest microprocessor technology available. Getting Started This manual will help in the installation, parameter setting, troubleshooting, and daily maintenance of the AC motor drive. VFD-E Series User Manual www.deltaww.com. Sensorless Vector Control Compact Drive VFD-E Series User Manual 1 4 EE 2016-05-16. I Preface Thank you for choosing DELTA’s high-performance VFD-E Series. The VFD-E Series is manufactured with high-quality components and materials and incorporate the latest microprocessor technology. Delta Electronics Braking Modules VFDB Series User Manual. For DELTA’s AC motor drive VFD Series, please set parameter (Over Voltage Stall Prevention). For the operation/stop method of the motor, please refer to the user manual of the AC Motor Drives VFD Series.
Preface
Thank you for choosing DELTA’s high-performance VFD-F Series. The VFD-F Series is
manufactured with high-quality components and materials and incorporates the latest microprocessor
technology available.
Getting Started
This quick start will be helpful in the installation and parameter setting of the AC motor drives. To
guarantee safe operation of the equipment, read the following safety guidelines before
connecting power to the AC motor drives. For detail information, refer to the VFD-F User Manual
on the CD supplied with the drive.
DANGER!
1.
AC input power must be disconnected before any wiring to the AC motor drive is made.
2.
A charge may still remain in the DC-link capacitors with hazardous voltages, even if the power
has been turned off. To prevent personal injury, please ensure that power has turned off before
opening the AC motor drive and wait ten minutes for the capacitors to discharge to safe voltage
levels.
3.
Never reassemble internal components or wiring.
4.
The AC motor drive may be destroyed beyond repair if incorrect cables are connected to the
input/output terminals. Never connect the AC motor drive output terminals U/T1, V/T2, and
W/T3 directly to the AC mains circuit power supply.
5.
Ground the VFD-F using the ground terminal. The grounding method must comply with the laws
of the country where the AC motor drive is to be installed. Refer to the Basic Wiring Diagram.
6.
VFD-F series is used only to control variable speed of 3-phase induction motors, NOT for 1-
phase motors or other purpose.
7.
VFD-F series shall NOT be used for life support equipment or any life safety situation.
WARNING!
1.
DO NOT use Hi-pot test for internal components. The semi-conductor used in AC motor drive
easily damage by high-pressure.
2.
There are highly sensitive MOS components on the printed circuit boards. These components
are especially sensitive to static electricity. To prevent damage to these components, do not
touch these components or the circuit boards with metal objects or your bare hands.
3.
Only quality person is allowed to install, wire and maintain AC motor drive.
CAUTION!
1.
Some parameters settings can cause the motor to run immediately after applying power.
2.
Delta Vfd B Series
DO NOT install the AC motor drive in a place subjected to high temperature, direct sunlight,
high humidity, excessive vibration, corrosive gases or liquids, or airborne dust or metallic
particles.
3.
Only use AC motor drives within specification. Failure to comply may result in fire, explosion or
electric shock.
4.
To prevent personal injury, please keep children and unqualified people away from the
equipment.
5.
When the motor cable between AC motor drive and motor is too long, the layer insulation of the
motor may be damaged. Please use a frequency inverter duty motor or add an AC output
reactor to prevent damage to the motor. Refer to appendix B Reactor for details.
6.
The rated voltage for AC motor drive must be
≤240V (≤480V for 460V models) and the mains
Delta Vfd L Manual
supply current capacity must be
≤5000A RMS (≤10000A RMS for the ≥40hp (30kW) models).
